Single Port 10/100/1000M Gigabit POE Injector 60W By Cat5 5e 6
Technical Parameters
| Standard | IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet IEEE 802.3af Power Over Ethernet IEEE 802.3at Power Over Etherent | |
| Interface | Data Input Port | 1-Port 10/100/1000Mbps TP |
| POE output port | 1-Port 10/100/1000Mbps TP | |
| Performance | POE (Power over Ethernet) | Max. 60Watt |
| Power Pin | Midspan +(1,2)(4,5), - (7,8)(3,6) | |
| LED Indicator | System: Power x 1 (green) PoE Port: Active, PoE ready-in-use x 1(green) | |
| PoE Output power | 48V ~ 56V | |
| Environmental | Temperature | Operation: 0℃ ~ 40℃ Store: - 40℃ ~ 70℃ |
| Humidity | 10 ~ 95% (Non-condensing) | |
| Input Voltage | 100~240VAC, 50/60Hz | |
Product Description:
This is a single-port PoE injector with one Ethernet port, one PoE output port, and one AC input power port. It supports end-span PoE and the output power consumption is up to 60W; It features:10/100/1000Mbps network,100m transmission distance,6KV lightning protection, industrial-level chip, and patent alert. it's an excellent choice for power supply and network transmission on PTZ cameras, all-in-one PC, digital display system.
Product picture
Packaging & Shipping
● All of our package are international standard package
● We will deliver our products as soon as the order confirmed
